NX 912-A is masterfully engineered from the ground up to deliver stellar audio performance for solo musicians, bands, and DJs. The combination of 1.75" compression driver, 12" woofer, two-channel 2100W amplifier, and a constant directivity waveguide produces coherent 100° x 60° coverage for the listening area with up to 130 dB SPL of distortion-free sound. Used stand-alone speaker for a FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 912-A blends high-performance and reliability in a compact package. Built specifically for demanding live sound applications, it also features multiple rigging points for fixed installation. Blending RCF proprietary FiRPHASE and Bass Motion Control DSP processing, NX 9 Series speakers are perfectly tuned for each model, delivering absolute clarity and deep, powerful bass response. The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.
Features:
-
Up to 130 dB Sound Pressure Level
-
2100W Class-D Bi-Amplification
-
50-20000 Hz linear frequency response
-
1.75" Compression Driver
-
12" Woofer
-
FiRPHASE zero degrees phase technology
-
Bass Motion Control woofer excursion management
Specifications:
-
Acoustical specifications:
-
FREQUENCY RESPONSE: 50 Hz ÷ 20000 Hz
-
MAX SPL @ 1M: 130 dB
-
HORIZONTAL COVERAGE ANGLE: 100°
-
VERTICAL COVERAGE ANGLE: 60°
-
Transducers:
-
COMPRESSION DRIVER: 1 x 1.0'', 1.75'' v.c
-
WOOFER: 12'', 2.5'' v.c
-
Input/Output section:
-
INPUT SIGNAL: bal/unbal
-
INPUT CONNECTORS: XLR, Jack
-
OUTPUT CONNECTORS: XLR
-
INPUT SENSITIVITY: -2 dBu/+4 dBu
-
Processor section:
-
CROSSOVER FREQUENCIES: 1600 Hz
-
PROTECTIONS: Thermal, RMS
-
LIMITER: Soft Limiter
-
CONTROLS: Linear, Boost, Stage, Volume
-
Power section:
-
TOTAL POWER: 2100 W Peak
-
HIGH FREQUENCIES: 700 W Peak
-
LOW FREQUENCIES: 1400 W Peak
-
COOLING: Convection
-
CONNECTIONS: VDE
-
Standard compliance:
-
Physical specifications:
-
CABINET/CASE MATERIAL: Plywood
-
HARDWARE: 2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1x M10 rear
-
HANDLES: 1 x Side
-
POLE MOUNT/CAP: Yes
-
GRILLE: Steel
-
COLOR: Black
-
Size:
-
HEIGHT: 620 mm / 24.41 inches
-
WIDTH: 362 mm / 14.25 inches
-
DEPTH: 405 mm / 15.94 inches
-
WEIGHT: 20.8 kg / 45.86 lbs
-
Shipping informations:
-
PACKAGE HEIGHT: 666 mm / 26.22 inches
-
PACKAGE WIDTH: 461 mm / 18.15 inches
-
PACKAGE DEPTH: 416 mm / 16.38 inches
-
PACKAGE WEIGHT: 22.8 kg / 50.27 lbs
