RCF ART 915-AX 15 inch 2-Way 2100 Watt Professional Active Speaker with Bluetooth

Video

Roll over image to zoom in or

Video

Save:

2x ART-915AX

Wishlist

Dealer

EZ Returns

Match

Overview
Specifications

The RCF ART 915-AX 2-Way PA Speaker is a top-notch 2100 watt professional solution for wide range of audio applications, featuring 48V microphone preamps and line inputs, an internal 6-channel digital mixer with advanced DSP, onboard effects, user-friendly large color touch display and a push encoder for easy sound optimization, Bluetooth® stereo audio input, with dual speaker pairing option.

This durable live sound active loudspeaker combines a 1.75" compression driver, 15" woofer, and two-channel 2100W amplifier. Whether you are mobile DJ or your band needs a main stage speaker you can count on reliable performance, 100° x 60° constant directivity coverage for the listening area with up to 131 dB SPL, distortion-free sound. RCF ART 915-AX with several operating modes, alone or paired with other speakers and/or subwoofers, wired or wireless, offers clear sound and secure connections.

The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.

With LiveRemote app you can manage the ART 915-AX from your smartphone or tablet - available for Android and iOS phones and tablets.

Features

• Built-in 6-channel Digital Mixer
• Advanced User Interface w/ touch panel and remote control
• 1.75" Compression Driver and 15" Woofer
• Up to 131 dB Sound Pressure Level
• 2100W Class-D Bi-Amplification
• Dual combo preamp with 48V Power and Mini-jack stereo line input
• Bluetooth® stereo audio input, with dual speaker pairing option
• True Resistive Waveguide, FiRPHASE, and Bass Motion Control

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

ACOUSTICAL SPECIFICATIONS
- Frequency Response: 45 Hz ÷ 20000 Hz
- Max SPL @ 1m: 131 dB
- Horizontal coverage angle: 100°
- Vertical coverage angle: 60°
TRANSDUCERS
- Compression Driver: 1 x 1.0'', 1.75'' v.c
- Woofer: 15'', 2.5'' v.c
INPUT/OUTPUT SECTION
- Input signal: bal/unbal
- Input connectors: Combo XLR/Jack
- Output connectors: XLR
PROCESSOR SECTION
Crossover Frequencies: 1600Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.
POWER SECTION
Total Power: 2100 W Peak, 1050 W RMS
High frequencies: 700 W Peak, 350 W RMS
Low frequencies: 1400 W Peak, 700 W RMS
Cooling: Convection
Connections: VDE
ELECTRONIC SPECIFICATIONS
Frequency Response: 20 Hz ÷ 20 Hz
THD+N, 20dB gain, 0dBu out: 0.005% A-Weighted
PROCESSING
Processing Channels: 6
Signal Processing: 24 Bit
A/D-D/A conversion: 32 Bit @ 48.0 kHz
Dynamic range: 110
INPUTS
Mic: 2
Remote Controlled Storable Gain: Yes
Gain Range: 0 dB ÷ 42 dB
Input Noise Level: -114 dBu A-Weighted
Mic Inputs Impedance: 6 kohm
Low Cut: 20 Hz ÷ 400 Hz
Phantom Power +48V: Yes
Mono Line: 2
Gain Selection: 0 dB ÷ 22 dB
Line Input Impedance: 21 kohm
A/D Dynamic range: 114 dB
Stereo Line: 1
Gain Selection: 0 dB ÷ 10 dB
Stereo Line Input Impedance (kOhm): 13 kohm
OUTPUTS
Main MIX: 1
OUTPUTS SPECIFICATIONS
Main Out Impedance: 150 ohm
Main Out Level: 22 dBu
D/A Dynamic Range: 114 dB
COMPRESSORS
RCF Compressors: Compressors on MIC/LINE CH1 & CH2 inputs.
EQ
Input Channels EQ: 2 Shelving 1
Description:
3 Band EQ: High and Low band shelving, MID band peak on IN
5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on Amplifier and MAIN output,
INTERNAL EFFECTS
Send Effects: 1
MASTERING PROCESSORS
Main OUT type: MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.
STANDARD COMPLIANCE
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material: PP Composite
Hardware: 1 x M10 top, 1 x M10 each side
Handles: 1 top, 1 each side
Pole mount/Cap: Yes
Grille: Steel
Color: Black
SIZE
Height: 717 mm / 28.23 inches
Width: 415 mm / 16.34 inches
Depth: 410 mm / 16.14 inches
Weight: 20.4 kg / 44.97 lbs
SHIPPING INFORMATION
Package Height: 760 mm / 29.92 inches
Package Width: 470 mm / 18.5 inches
Package Depth: 475 mm / 18.7 inches
Package Weight: 24.5 kg / 54.01 lbs
