JBL PRO 305PMKII Powered 5" Two-Way Studio Monitor

JBL PRO 305PMKII Powered 5" Two-Way Studio Monitor
Roll over image to zoom in or click & view gallery
Video
  • Live Presentation of the 305PMKII and other JBL 3 Series MkII Speakers at NAMM 2018
$189.00
New/Sealed icon-info

FREE Shipping

In Stock - Ready to Ship

Qty:

Affirm Available

Extended Warranty Coverage CPS Extended Warranty Coverage. Get the Details
Authorized Dealer Dealer
Returns EZ Returns
Price Matching Match
The next-generation JBL 305P MkII compact powered 2-way active studio monitor speaker makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers, JBL 305P MkII offers stunning detail, precise imaging, a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace.

To help you make the best mix decisions, JBL equipped the 305P MkII with improved transducers. Hear deep, accurate and tightly controlled bass thanks to a long-throw 5" woofer and the patented JBL Slip Stream™ low-frequency port. 1" Neodymium tweeter for clear sound is on the HF side and dual integrated Class D power amplifiers for each transducer.

Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors, and sporting a sleek, modern design, 82W JBL 305P MkII speakers delivers outstanding performance and an enjoyable mix experience especially for monitoring your mixes at home and for DJ starters.


Features:
  • • Patented Image Control Waveguide for detailed imaging and a broad, room-friendly sweet spot
  • • Next-generation JBL transducers for optimized transient response and improved linearity
  • • Patented Slip Stream™ low-frequency port for superior bass performance at all playback levels
  • • Dual integrated, custom Class-D amplifiers provide 82 watts of power for high output and dynamic range
  • • New Boundary EQ settings compensate for low frequency variants introduced by the environment
  • • HF Trim switch adjusts high-frequency output to room acoustics or personal preferences
  • • Flexible connectivity with balanced XLR and 1/4" TRS inputs, +4dBu / -10dBV input-sensitivity switch and adjustable volume control
  • • Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any working space
  • • Strenuous JBL 100-hour full-power test ensures years of reliability
  • • Sleek, modern design provides a visual upgrade to any studio




WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • LF DRIVER SIZE:
  • 203mm (5")
  •
  • HF DRIVER SIZE:
  • 25mm (1")
  •
  • HF DRIVER TYPE:
  • Soft dome
  •
  • CROSSOVER:
  • 1725Hz 4th order acoustic Linkwitz-Riley
  •
  • OK FOR USE NEAR MAGNETICALLY SENSITIVE EQUIPMENT -  Yes
  •
  • INPUT SENSITIVITY (-10dBV INPUT):
  • 92dB / 1m
  •
  • POWER CONFIGURATION:
  • Bi-amplified
  •
  • HF DRIVER POWER AMP:
  • 41W, Class-D
  • LF DRIVER POWER AMP:
  • 41W, Class-D
  •
  • FREQUENCY RESPONSE (±3dB):
  • 49Hz – 20kHz
  • FREQUENCY RANGE (-10dB):
  • 43Hz – 24kHz
  • LOW FREQUENCY EXTENSION (-10dB):
  • 43Hz
  •
  • MAXIMUM CONTINUOUS SPL:
  • 94dB
  • MAXIMUM PEAK SPL:
  • 108dB
  •
  • MAXIMUM PEAK INPUT LEVEL (-10dBV / +4dBu):
  • +6dBV / +20.3dBu
  •
  • SYSTEM DISTORTION CRITERIA:
  • <10% THD at maximum output with full compressor / limiter engagement
  •
  • ELECTRICAL DISTORTION CRITERIA:
  • 0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output
  •
  • SIGNAL TO NOISE RATIO:
  • 75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output
  •
  • COVERAGE:
  • HORIZONTAL x VERTICAL 120° x 90°
  •
  • ANALOG INPUT TYPES:
  • 1 x XLR female, 1 x TRS female, balanced
  •
  • HF TRIM CONTROL:
  • -2dB, 0dB, +2dB
  •
  • BOUNDARY EQ:
  • LF Shelf @ 50Hz: -3dB, -1.5dB, 0dB
  •
  • AC INPUT VOLTAGE:
  • 100 – 240VAC (±10%), 50 / 60Hz
  •
  • ENCLOSURE TYPE: Ported
  •
  • ENCLOSURE CONSTRUCTION:
  • 15mm MDF
  •
  • ENCLOSURE FINISH:
  • Matte black PVC
  •
  • BAFFLE CONSTRUCTION:
  • Injection-molded structural ABS
  •
  • CABINET DIMENSIONS (H x W x D):
  • 298 x 185 x 231 mm (11.75" x 7.3" x 9.9")
  •
  • DISPLAY CARTON (H x W x D):
  • 354 x 244 x 299mm (13.9" x 9.6" x 11.8")
  •
  • SHIPPING CARTON (H x W x D):
  • 373 x 260 x 315mm (14.7" x 10.2" x 12.4")
  •
  • NET WEIGHT:
  • 4.73 kg (10.43 lbs)
  • SHIPPING GROSS WEIGHT:
  • 5.72 kg (12.61 lbs)
